Smooth Surface Hydraulic Rubber Hose with High Quality China Good Price

Date：2023-09-20 09:50:50VIew：

SANYEFLEX Professional Manufacturer for High-end High Quality Flexible Hydraulic Hose, Industrial Hose

Products Range:

√ Hydraulic Hose √ Automobile Air Conditioning Hose√ Industrial Hose√ Fittings & Couplings

SAE 100 R1AT / DIN 1SN
SAE 100 R2AT / DIN 2SN
DIN EN 857 1SC
DIN EN857 2SC
DIN EN 856 4SH
DIN EN 856 4SP
(Contact us for more Model NO.)

SAE 100R1 AT/DIN EN 853 1SN
INNER TUBE: oil resistant synthetic rubber
REINFORCEMENT: one high tensile steel wire braid
COVER: abrasion and weather resistant synthetic rubber
TEMPERATURE RANGE: -40ºC to +100ºC

HOSE ID		Wire OD	Hose OD	Working Pressure		Burst Pressure		Minimum Bend Radius	Weight
Inch	mm	mm	mm	MPa	Psi	MPa	Psi	mm	kg/m
3/16	4.8	9.5	11.8	25.0	3630	100	14280	90	0.19
1/4	6.4	11.1	13.4	22.5	3270	90	12840	100	0.21
5/16	7.9	12.7	15.0	21.5	3120	85	12280	115	0.24
3/8	9.5	15.1	17.4	18.0	2610	72	10280	130	0.33
1/2	12.7	18.3	20.6	16.0	2310	64	9180	180	0.41
5/8	15.9	21.4	23.7	13.0	1890	52	7420	200	0.45
3/4	19.0	25.4	27.7	10.5	1530	42	6000	240	0.58
1	25.4	33.3	35.6	8.8	1280	35	5020	300	0.88
1-1/4	31.8	40.5	43.5	6.3	920	25	3600	420	1.23
1-1/2	38.1	46.8	50.6	5.0	730	20	2860	500	1.51
2	50.8	60.2	64.0	4.0	580	16	2280	630	1.97

Wrapped Surface Hydraulic Hose Smooth Surface Hydraulic Hose

Smooth Hydraulic Hose

For the smooth hydraulic hose cover, a plastic sheath is textured around the hydraulic hose, and the plastic sheath is used to press the hydraulic hose cover during the curing process, but not leave any visible vestiges. In this method, we get the smooth surface of the hydraulic hose. The hydraulic ventilation with smooth bore works for you to get the smooth hydraulic hose surface.

We use plastic-coated materials to create a smooth cover for the hydraulic hose, and the plastic-coated material can give better abrasion performance to the hydraulic hose body.

Application

Company ProfileHebei Sanye Fluid Technology Co., Ltd. is a China-US cooperative enterprise. SANYEFLEX has strong financial strength and technical strength. Our factory occupies a total area of 110,000 square meters, with a plant area of 70,000 square meters and a total investment of 65 million yuan. Our company has been deeply involved in the hydraulic hose industry for nearly 20 years. We have two technical research and development teams, and more than 40 on-the-job engineers are respectively dedicated to technical research in the field of hydraulic fluids and development of refrigeration systems.
Our company specializes in the production of mid-high-end hydraulic hose series products, such as steel wire braided hose (American standard, German standard), steel wire spiral hose (American standard, German standard), metal hose, air pipe and joints and other products. With excellent product quality, perfect after-sales service and reasonable price, we gradually increase the market share of our products. Our products are widely used in mining, metallurgy, petroleum, construction machinery and chemical industry, and are exported to more than 30 countries and regions such as the United Kingdom, the United States, Germany, South America and Russia. The company adheres to the core values of "integrity-based, customer first". Unswervingly promote the development concept of "leading by originality, developing talents, rooting in leanness, and bravely climbing the peak". Carry out technical R&D and manufacturing closely around customer needs, provide first-class services to a broad audience, and strive to become an industry leader. Our Purpose

For Our End Customers, to SAVE DOWNTIME, SAVE maintenance COSTS, INCREASE PROFITS for enterprise.

For our Dealer Customers, to get MORE STABLE CUSTOMERS to PROMOTE the DEVELOPMENT of their enterprises.

Factory tourLaboratory

Packaging & Shipping

Why Choose SANYEFLEX?

Specialized in hydraulic hose production research and development for 20 years, has rich experience and technology.
Imported raw materials directly from the United States, Japan, South Korea.
Automatic mixer workshop.
Using intelligent production line fully automated transfer process
Each hose are pass strict inspection before delivery.
Reliable product quality, safety performance is high, reduce the cost of the enterprise.

FAQ

Q1:Can you do OEM?
A: Yes, we can do OEM products. Welcome!

Q2: Are you a factory or trading company?
A: Factory! We are 100% manufacturer, and we have 20 years experience in hydraulic rubber hose production. Welcome to visit our factory.

Q3: Is free sample available?
A: Yes, free samples available, customer only pay freight cost.

Q4: How about your delivery time?
A: Within 20 days after you pay the payment.

Q5: What's your terms of packing?
A: Generally in rolls by well wrapped with colorful poly stripes or as your requirement.

Q6: What's your terms of payment?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.

We are Happy to Quote for you, Contact Us Right Now!
